Integrations — the launcher rail

The launcher rail is the row of small icon chips that lives in the top chrome strip (or in the left sidebar when tab_layout = "vertical"). Each chip launches a configured command as a new tab when clicked. The rail is configured by [[ui.launcher_icon]] entries in ~/.config/tmnl/config.toml, but you almost never edit that file by hand — the Add integration discovery overlay drives the rail through a keyboard-first picker that knows about every family sibling tmnl knows about, whether you have it installed or not.

This page covers both surfaces — the rail and the overlay — and the small amount of TOML they manage on your behalf.

The launcher rail

Each chip in the rail is one LauncherIcon:

[[ui.launcher_icon]]
id = "mnml"
glyph = ""             # nerd-font glyph or any character
command = "mnml"             # binary on $PATH, OR :builtin sentinel
args = []                    # optional argv
tooltip = "mnml editor"
color = "#89b4fa"            # accent color for the chip

Click a chip and tmnl spawns the command as a new pty tab — the same code path New Tab takes, but the entry command is the launcher’s binary instead of $SHELL. The chip strip’s hit-rects track the actual painted glyph position (including the window-padding-balance offset, so the click target lines up with what you see — fixed in 1aaaaaf).

Rail position is controlled by launcher_position:

| Value | Layout | | --- | --- | | top (default) | Inline in the top chrome strip, after the tab chips. | | left | Narrow vertical rail at the window’s left edge. | | bottom | Painted at the last row of the body. |

The rail auto-hides when the focused pane is Native (mnml / mixr ship their own activity bars; the duplicate tmnl-side rail just steals body width). Switching to a Shell tab brings it back.

Built-in commands

Two catalog entries are built into tmnl core. Their command field is a :colon-prefixed sentinel rather than a real $PATH binary, and new_launcher_tab dispatches them before attempting to spawn:

| Sentinel | Effect | | --- | --- | | :browser | Opens an embedded browser pane as a new tab at args[0] (default DuckDuckGo). See Browser pane. | | :http | Opens a scratch .http file in $EDITOR (or mnml as the family fallback). args[0] overrides the editor; args[1] overrides the path. Default path ~/.cache/tmnl/scratch.http is created with a sample GET request on first use. |

Unknown sentinels log a warning instead of silently failing.

The discovery overlay

The + chip on the rail (at the end of the chip strip; on its own row when the rail is empty) opens the discovery overlay. Also reachable from:

• ⌘⇧I
• View > Add Integration…
• Shell > Integrations > Manage Integrations…

The overlay lists every entry in src/family_catalog::CATALOG — every family sibling tmnl knows about — with one of three states:

| Tag | Meaning | | --- | --- | | [in rail] (green) | Already configured in cfg.launcher_icons. Enter removes it. | | [installed] (green) | Binary is on $PATH (or a well-known install dir) but not in your rail. Enter adds it. | | [not installed] (red) | Binary isn’t anywhere we looked. Enter copies the install command to your clipboard so you can paste-run it in a shell pane. |

Built-in entries (:browser, :http) are always treated as [installed] — no $PATH lookup, you can add them with one keystroke.

Layout

The list is split into two visually distinct sections:

── In rail ──  cmd+↑↓ reorder
  [in rail]   M  mnml    mnml — NvChad-style ratatui …
  [in rail]   C  claude  Claude Code — Anthropic's CLI …
  [in rail]   ♪  mixr    Family DJ app — docked panel …

── Editor ──
  …
── AI assistants ──
  [installed]   X  codex  Codex — OpenAI's CLI coding …
── AWS ──
  [not installed]  ☁  mnml-aws-codebuild …

1. In rail — every InRail row in cfg.launcher_icons order (= the chip order in the strip). Doubles as a live preview of what the rail currently looks like.
2. Catalog — every non-rail row grouped by category. InRail rows are hidden here to avoid duplication.

Each row paints [tag] / glyph / binary / one-liner, aligned to a fixed-column tag layout (15-cell tag column, then glyph, then name) so [in rail] (9 cells) and [installed] (11 cells) line up cleanly with the wider [not installed] (15 cells). The glyph paints in the same accent color the chip will use once added, so you can preview the result before committing.

Keys

| Key | Effect | | --- | --- | | ↑ / ↓ | Move the focused row. | | ⌘↑ / ⌘↓ | Swap the focused In-rail row with its neighbor in cfg.launcher_icons (= visual swap in the strip). No-op on non-rail rows. | | any printable char | Append to the substring filter. | | Backspace | Drop the last filter character. | | Enter | Fire the focused row’s action. Overlay stays open so multiple entries can be added in one session. | | Esc | Dismiss. |

Every other key is consumed (greedy) — the overlay never leaks input to the background pty. The filter matches case-insensitively against the sibling’s binary name, its one-liner, and its category header.

Mouse

| Action | Effect | | --- | --- | | Click a row | Focuses it and fires the same action as Enter. | | Click outside the overlay box | Dismisses (mirrors the macOS panel UX). | | Wheel | Scrolls the focused row. |

The renderer publishes last_row_layout (cell-y → visible row index) + last_rect (the overlay’s box) every paint; the click handler does a direct hit-test against those so the row math never drifts from what’s on screen.

Multi-select

Enter doesn’t close the overlay — it fires the focused row’s action and then re-derives every row’s state so the just-acted row’s tag flips live ([installed] → [in rail] after an add; the opposite after a remove). Hit Enter on the same row twice to toggle back. The pattern lets you set up your full rail in one overlay session: type a filter, Enter, clear filter, type the next one, Enter, repeat. Esc when done.

Reordering

⌘↑ / ⌘↓ while focused on an In-rail row swaps it with its neighbor in cfg.launcher_icons. The strip’s chip order tracks that order, so the chip moves left/right (or up/down on a vertical rail) live. The overlay’s row stays focused on the same sibling so the cursor visually follows the moved row.

Reordering is a no-op on non-rail rows — categories aren’t user-orderable.

Auto-refresh of stale ASCII fallback glyphs

The catalog ships nerd-font glyphs (e.g. mnml-patched  for Claude Code,  for mnml itself). Earlier sessions of the catalog shipped defensive single-ASCII fallbacks (M, C, X) for users whose font didn’t have the nerd-font slots; those got persisted into launcher_icons entries on disk.

Opening the discovery overlay now scans your rail for single-ASCII-letter glyphs and quietly upgrades them to the current catalog glyph + color (family_catalog::refresh_stale_glyphs). Conservative on purpose: anything that doesn’t look like a single ASCII letter is left alone, so a user who manually picked a custom glyph (♪, ★, an emoji) won’t see it silently overwritten.

Color resolution

Catalog rows ship colors as standard names ("yellow", "pink", "blue") rather than hexes — easier to read in source. On insert into launcher_icons, the name is resolved to a #rrggbb via IconTemplate::color_hex before being written to disk, so the strip’s parse_hex_rgba always reads a valid hex. Unknown names fall back to a neutral gray. Custom hex strings ("#abcdef") are written through unchanged.

Install command copy

For [not installed] rows, Enter copies the install command to your clipboard so you can paste-run it in a shell pane. The shape depends on the sibling:

• Cargo siblings (most family entries): cargo install --git https://github.com/chris-mclennan/<repo> --tag vX.Y.Z <binary>
• npm CLIs (Claude Code, Codex): npm install -g @anthropic-ai/claude-code
• Built-in entries (:browser, :http): A no-op note explaining the binary ships with tmnl/mnml core.

After running the install, re-opening the overlay re-scans $PATH and the row flips from [not installed] to [installed] — one more Enter adds it to the rail.

The underlying TOML

The overlay writes back to ~/.config/tmnl/config.toml. A typical rail ends up looking like:

launcher_position = "top"

[[ui.launcher_icon]]
id = "mnml"
glyph = ""
command = "mnml"
args = []
tooltip = "mnml editor"
color = "#89b4fa"

[[ui.launcher_icon]]
id = "claude_code"
glyph = ""
command = "claude"
args = []
tooltip = "Claude Code"
color = "#f9e2af"

[[ui.launcher_icon]]
id = "browser"
glyph = ""
command = ":browser"
args = ["https://duckduckgo.com"]
tooltip = "Open browser tab"
color = "#89b4fa"

You can edit this file directly — the rail picks up changes on the next launch — but the overlay is the supported workflow. Hand-editing is for things the overlay doesn’t cover yet (custom start URL for :browser, custom scratch path for :http, swapping the catalog glyph for a custom character).

The menu surface

The same launcher rail is mirrored as Shell > Integrations — one menu item per chip, labels prefer the icon’s tooltip (e.g. Claude Code) over the raw binary. Clicking an item fires App::new_launcher_tab(idx) — the exact same code path the rail chip click takes. Empty rail shows (no integrations configured). A Manage Integrations… trailer at the bottom always opens the discovery overlay, so the menu is a discoverable surface for users who don’t see the rail (launcher_position = "left" on a narrow window, force-hidden tab bar, etc.).

Shell > Splits > Split with Integration ▸ is the same list with a different dispatch: click splits the active pane instead of spawning a new tab.

Where to go next

• Tabs, splits, and panes — what a launcher chip click actually opens.
• Browser pane — the :browser built-in’s pane kind and its chrome strip.
• Multi-window — cfg.launcher_icons is one of the per-window-cfg-overrideable knobs.
• Menu bar reference — how the dynamic Shell > Integrations submenu hangs off the rail config.
• The catalog: src/family_catalog.rs.
• The overlay: src/discovery_overlay.rs.
• The dispatch: src/app_tabs.rs::new_launcher_tab.
