Standards & protocols

Terminal emulators are layered specs. ECMA-48 from 1976 gave us cursor movement, SGR colors, and the basic CSI grammar; xterm added a handful of extensions through the 80s and 90s; DEC contributed Sixel; iTerm2 added inline images; Kitty rebuilt keyboard handling from scratch. Modern terminals are a sum of these, and modern shells, editors, and TUIs assume they’re all there.

This page catalogues every spec tmnl’s shell mode implements, with the source-of-truth source file, the wire format, and any tmnl-specific notes. Shell mode is the pty-hosting track that shares wire compatibility with xterm, kitty, iTerm2, WezTerm, and friends. Native mode has its own protocol — tmnl-protocol — covered at the end of this page.

Where each scanner lives

Each spec gets its own module under src/: osc7.rs, osc8.rs, osc9.rs, osc22.rs, osc52.rs, osc99.rs, osc133.rs, osc1337_file.rs, osc_palette.rs, csi_modes.rs, csi_rep.rs, csi_responses.rs, csi_title_stack.rs, csi_underline_color.rs, underline_sgr.rs, decscusr.rs, decstr.rs, mode_query.rs, kitty_graphics.rs, kitty_kbd.rs, sixel.rs, shell_mouse.rs. The reader thread runs each scanner over the pty byte stream before handing the bytes to the vt100 parser — vt100 0.16 silently drops most of these, so peeling them off first is the only path that surfaces them at all.

OSC sequences

OSC (“Operating System Command”) sequences carry side-channel commands that don’t produce visible output: set the title, change a color, ring a bell, mark a prompt boundary. The shape is always the same:

ESC ] <number> ; <payload> ST

ST (string terminator) is either BEL (0x07) or ESC \. tmnl accepts both forms everywhere.

OSC 7 — current working directory

xterm sequences · source: src/osc7.rs

Shells emit ESC ] 7 ; file://<host>/<percent-encoded-path> ST after each cd. tmnl extracts the path to drive per-pane cwd-aware UI — tab-label fallback, “open in Finder” actions, and future remote-aware integrations. Over SSH, OSC 7 is the only reliable way for tmnl to learn the remote shell’s cwd.

The host portion is informational and dropped. Percent-encoded escapes (%20 for space, etc.) are decoded; unknown escapes pass through literally so we never lose user bytes.

OSC 8 — hyperlinks

VTE hyperlink spec · source: src/osc8.rs

The de-facto “clickable text in the terminal” protocol:

ESC ] 8 ; <params> ; <uri> ST   <visible text>   ESC ] 8 ; ; ST

The closing sequence has both params and URI empty. tmnl tags each cell covered by an “open” segment with a link id in a parallel grid, so the existing mouse-hover and cmd+click paths work uniformly. Params (commonly id=<some-id>) are parsed but ignored — per-cell tagging gives the same visual effect without tracking ids.

Common emitters tmnl handles in the wild: gh CLI, gitui, ls --hyperlink=auto, git log recent versions, GNU grep --color=always.

OSC 9 — ConEmu / iTerm2 extensions

ConEmu OSC 9 spec · iTerm2 proprietary escape codes · source: src/osc9.rs

Two forms share the OSC 9 prefix:

• ESC ] 9 ; <message> ST — desktop notification (iTerm2 style).
• ESC ] 9 ; 4 ; <state> ; <percent> ST — progress report (ConEmu style).

Progress states: 0 clear, 1 normal, 2 error tint, 3 indeterminate (spinning), 4 paused. tmnl auto-clears the progress chip after 15 s of inactivity, mirroring Ghostty’s convention, so a crashed cargo build doesn’t pin a stale bar forever.

Programs that emit these: cargo, npm/pnpm, make 4.4+, apt, Windows installers, plus iTerm2 shell-integration on long-running command completion. Unknown sub-IDs fall back to “treat as notification body” — again matching Ghostty.

OSC 22 — mouse-cursor shape

VTE OSC 22 · source: src/osc22.rs

Programs ask the terminal to change the mouse-cursor shape:

ESC ] 22 ; <shape-name> ST

<shape-name> is an X11 cursor-spec keyword — text / pointer / hand / crosshair / wait / progress / not-allowed / ew-resize / ns-resize / move / help, plus aliases like xterm, default, hand1. The App polls each tick and calls winit::Window::set_cursor when the shape on the focused pane changes.

Empty body or ? is a query; tmnl doesn’t reply (matching Ghostty’s behavior for unknown shapes).

OSC 52 — read/write system clipboard

xterm OSC 52 · source: src/osc52.rs

The killer use case is SSH: yy in vim on a remote host can land in the local Mac’s pasteboard without tmux clipboard forwarding, without pbcopy over ssh, without any clipboard daemon.

ESC ] 52 ; <targets> ; <base64> ST

Targets are one or more of c (clipboard), p (primary), s (selection), or 0–7 (xterm cut buffers). tmnl owns one OS pasteboard per platform, so any non-empty target string maps to “clipboard.” Empty payload after the targets is a query — tmnl silently ignores it (never echoes the pasteboard back into the pty, for security).

Paste-protect: large multi-line payloads route through the same confirm dialog as ⌘V, blocking the multi-line-clipboard-injection attack class where a remote process tries to forge an “rm -rf …” that the user “approves” by pressing Enter.

OSC 99 — Kitty notifications

Kitty notification protocol · source: src/osc99.rs

Kitty’s richer notification protocol — colon-separated key=value metadata, then the body:

ESC ] 99 ; <metadata> ; <body> ST

tmnl v1 supports n=<title>, i=<id> (notification id; replaces prior sends with the same id), and p=<priority> (0 low, 1 normal, 2 critical). Skipped for v1: e= (encoding alternatives), d= (multi-chunk done marker), s= (sound), u=/a= (action buttons), o= (sticky/close-on-click). The common path — gh notify / cargo build done / notify-send-equivalents — only uses n= + body.

OSC 133 — semantic prompts

VS Code shell integration overview · FinalTerm OSC 133 spec · source: src/osc133.rs

The four-mark “FinalTerm” semantic-prompt protocol — A (prompt about to draw), B (command input begins), C (output begins), D[;exit] (command finished). With the shell-integration snippet installed, tmnl folds these into per-session lifecycle state that drives:

• The ✗N tab-strip chip for non-zero exits.
• ⌘↑ / ⌘↓ jump-to-prompt navigation through scrollback.
• The command-line anchor that AI command completion (⌘I / ⌘K) reads to know where the editable input starts.

Without the snippet, no marks arrive and the state stays inert. Every consumer degrades gracefully.

OSC 1337 — iTerm2 proprietary escape codes

iTerm2 docs · sources: src/osc1337_file.rs, src/shell_osc1337.rs (attention scanner)

iTerm2’s catch-all prefix carries several sub-grammars; tmnl recognizes two:

ESC ] 1337 ; File = <keys> : <base64> ST — inline image display. Decodes PNG via the image crate and JPEG via jpeg-decoder, normalizing both into the same kitty_graphics::Image representation so the rest of the renderer treats OSC 1337 images identically to Kitty graphics. Honored keys: name, size, width/height (cells, Npx, N%, or auto), preserveAspectRatio, inline. Skipped: file transfer (inline=0), GIF (use the Kitty graphics path).

ESC ] 1337 ; RequestAttention=... ST — attention signal. Claude Code uses this when a turn finishes and is waiting for input. tmnl doesn’t parse the iTerm2 sub-grammar (Notify=…, RequestAttention=…, StealFocus) — any OSC 1337 payload flips the pane’s attention flag, which surfaces through the dock badge / chime / prompt-path attention chip. See Attention & notifications. The cost of this coarse-grained approach is a few harmless false-positives when vim or tmux emits other 1337 sequences (cursor color, etc.).

OSC 4 / 10 / 11 / 12 / 104 / 110 / 111 / 112 — palette ops

xterm Operating System Commands · source: src/osc_palette.rs

xterm’s palette set/reset/query family:

| Sequence | Meaning | | --- | --- | | OSC 4 ; <idx> ; rgb:rrrr/gggg/bbbb ST | set palette color <idx> (0–255) | | OSC 10 ; rgb:... ST | set default foreground | | OSC 11 ; rgb:... ST | set default background | | OSC 12 ; rgb:... ST | set cursor color | | OSC 104 | reset all palette indices | | OSC 104 ; <idx> ST | reset palette index | | OSC 110 / 111 / 112 | reset default fg / bg / cursor |

Query form substitutes ? for the color spec. tmnl replies to query forms (OSC 10 ; ? ST, etc.) so Neovim’s light-vs-dark background autodetection (&background) works. Color spec accepts rgb:RRRR/GGGG/BBBB (xterm canonical) or #RRGGBB / #RRRRGGGGBBBB (compat); each channel may be 1 to 4 hex digits and normalizes to 0..=255.

OSC 13 / 14 (mouse fg/bg), 15 / 16 / 18 (Tektronix), and a handful of less common slots are also parsed for completeness.

CSI extensions

CSI (“Control Sequence Introducer”) sequences start with ESC [ and are the workhorse of terminal control — cursor movement, color, mode toggles, queries. The sub-grammar is intricate; tmnl peels off the parts vt100 0.16 doesn’t handle.

REP — CSI Ps b

ECMA-48 §8.3.103 · source: src/csi_rep.rs

“Repeat the previous graphic character Ps times.” Originally an ECMA-48 hold-over for line-drawing run-length compression; modern programs use it as a bandwidth optimization for long runs (seq, ncurses horizontal rules, some progress bars).

vt100 0.16 drops b-terminated CSI sequences. tmnl expands REP in the reader thread before passing the chunk to vt100: scan for the marker, look back for the last printable character, splice in (count - 1) extra copies. Capped at 64 KiB total expansion to defend against CSI 99999 b pathologies.

Colon-subparameter underline styles — CSI 4:N m

Kitty colored-text underline styles · source: src/underline_sgr.rs

Modern underline styles via SGR colon-subparameter:

ESC [ 4:0 m   off
ESC [ 4:1 m   single
ESC [ 4:2 m   double
ESC [ 4:3 m   curly       (LSP diagnostics, spell-check)
ESC [ 4:4 m   dotted
ESC [ 4:5 m   dashed

vt100 0.16 only knows the legacy CSI 4 m / CSI 24 m forms. tmnl peels the colon-subparameter form off the byte stream, emits one transition event per change, and the reader thread carries a parallel underline_grid so apply_to_grid can tag the right attribute bits. Legacy 4 m / 24 m also flow through the same scanner so the parallel grid stays in sync when a session mixes both forms.

Colored underlines — CSI 58 … / CSI 59 m

Kitty colored-text underline styles · source: src/csi_underline_color.rs

Mirrors the 38/48 form for foreground/background, but for the underline color. Both the semicolon-canonical xterm form and the colon-subparameter ITU canonical form are accepted:

CSI 58 ; 2 ; R ; G ; B m         true-color (xterm-original)
CSI 58 : 2 :: R : G : B m        true-color, colon-subparam (ITU canon)
CSI 58 ; 5 ; <idx> m             8-bit indexed
CSI 59 m                         reset to default (= fg)

Indexed form resolves the index against the per-pane PaletteState.indexed override, so a program themed via OSC 4 gets its undercurl colors following the theme.

DECSET / DECRST mode toggles

xterm DECSET · source: src/csi_modes.rs

Programs ask the terminal to enable / disable various features:

ESC [ ? <n> h     enable mode <n>
ESC [ ? <n> l     disable mode <n>

The modes tmnl tracks today:

| Mode | Meaning | tmnl note | | --- | --- | --- | | ?1000 | X10 mouse press-only | tracked; encoder honors press-only | | ?1002 | mouse drag (button motion) | write_mouse_motion reports drag | | ?1003 | mouse hover + drag (any motion) | write_mouse_motion reports all motion | | ?1004 | focus reporting | terminal sends ESC [ I / ESC [ O on focus changes | | ?1006 | SGR mouse encoding | extended-range coordinates; the canonical modern form | | ?2004 | bracketed paste | cmd+v wraps payload in ESC [ 200~ / ESC [ 201~ | | ?2026 | synchronized output | renderer keeps the prior frame until the unmatched ?2026 l arrives |

Sequences are still forwarded to vt100 normally; vt100 handles its own internal mode tracking (cursor visibility, etc.) independently. tmnl’s parallel state is what surfaces user-facing behavior — flipping ?2004 off makes cmd+v send raw bytes; flipping ?1004 on makes window focus generate input.

Title-stack window manipulation — CSI 22 t / CSI 23 t

xterm window manipulation · source: src/csi_title_stack.rs

Push and pop the current title onto a per-pane stack — vim, less, and fzf use this to set a transient title and restore the prior one on exit.

CSI 22 [;Ps] t   push (0 = both, 1 = icon, 2 = window)
CSI 23 [;Ps] t   pop

tmnl carries one label per pane (the tab strip displays the window title); icon-only push/pop (Ps=1) becomes a no-op at the TitleSink level while still consuming the byte sequence. vt100 0.16 silently drops t-terminated CSI sequences entirely, so this scanner is the only path that surfaces them.

Device & status queries — CSI c, CSI n, CSI t

xterm Device Attributes · source: src/csi_responses.rs

Without responses to these, Neovim assumes “ancient VT100” mode and disables modern features; htop picks a conservative color depth; image-rendering tools can’t compute scale.

| Query | Reply | | --- | --- | | CSI c (primary DA) | terminal class | | CSI > c (secondary DA) | terminal version | | CSI = c (tertiary DA) | DCS device-id sequence | | CSI 5 n (DSR — “are you OK?”) | CSI 0 n (“OK”) | | CSI 14 t | window pixel size | | CSI 18 t | text-area cell size |

Each emits an Event the reader thread translates into a pre-built reply pushed to pending_pty_writes.

Mode-state queries — DECRQM / DECRQSS

xterm DECRQM · source: src/mode_query.rs

Programs probe terminal capability via these. Neovim checks whether it actually enabled ?2004 (bracketed paste) before emitting paste-wrapped sequences; some shells check ?2026 before starting a sync transaction.

DECRQM   CSI [?] Ps $ p       — query mode state (set / reset / permanent)
DECRQSS  DCS $ q Pt ST        — query setting (SGR, DECSCUSR, margins, conformance)

DECRQM reply uses Pm values: 0 (unknown), 1 (set), 2 (reset), 3 (permanently set), 4 (permanently reset). tmnl tracks every mode the csi_modes scanner surfaces, plus a handful of “definitely set” / “definitely reset” replies for modes the terminal can’t toggle.

DECSCUSR — set cursor style — CSI Ps SP q

VT520 DECSCUSR · source: src/decscusr.rs

Programs like vim, Neovim, zsh-vi-mode, and fish flip the cursor style between modes (block in normal, bar in insert, underline in replace):

| Ps | Shape | Blink | | --- | --- | --- | | 0, 1 | block | yes | | 2 | block | no | | 3 | underline | yes | | 4 | underline | no | | 5 | bar / I-beam | yes | | 6 | bar | no |

tmnl tracks the shape on the focused pane’s ShellSession and the App reads it when applying the cursor attr to the cell at the vt100 cursor.

DECSTR — soft reset — CSI ! p

VT510 DECSTR · source: src/decstr.rs

“Please reset to a sane default state.” tmux sends this on attach to recover from whatever state the previous attached process left things in; some shell programs send it on init for the same reason.

vt100 0.16 doesn’t handle DECSTR, so tmnl detects the sequence and resets the parallel state tmnl tracks above vt100: bracketed paste, focus reporting, sync depth, Kitty keyboard flags, cursor style, cursor blink, palette overrides, underline and link grids, and the OSC 8 / OSC 4:N continuation state on the reader side. Nothing vt100-owned gets reset — a “true” DECSTR would reset cell colors too, but that mismatches what real programs expect from our parallel state (a stuck sync_depth > 0 from a crashed program being the biggest concrete win).

Graphics protocols

Three competing inline-image specs coexist in the terminal world. tmnl implements all three and normalizes them into the same internal Image + Placement representation so the GPU pipeline doesn’t care which one drew the image.

Kitty graphics protocol

Kitty graphics protocol · source: src/kitty_graphics.rs

The richest of the three. Wire shape:

ESC _ G <key1=val1,key2=val2,...> ; <base64-payload> ESC \

tmnl v1 implements the “core path” that covers kitty +icat, imgcat, and most gh / lazygit use cases:

• a=T (transmit and display)
• f=100 (PNG payload) and f=24 / f=32 (raw RGB / RGBA)
• t=d (direct / inline transmission)
• m=0 (single chunk; multi-chunk m=1 is deferred)
• c=<cols> / r=<rows> — placement size in cells (the missing axis is picked to preserve aspect ratio)
• s=<px> / v=<px> — image pixel dimensions (required for raw formats)
• i=<id> — image id (defaults to a per-pane sequential)

Deferred (parsed but ignored or rejected): t=f / t=t / t=s (file / temp / shared-memory transmission), o=z (zlib), a=d (delete), a=q (query), z= (z-index), x / y / w / h (source region offsets), p= (placement id), Unicode placeholder positioning, animation frames.

Sixel — DEC pixel graphics

All About SIXELs · source: src/sixel.rs

The DEC original. Sixel encodes 6-pixel-tall vertical strips of an image as printable ASCII characters (0x3F..0x7E mapped to a 6-bit bitmap). Common emitters: img2sixel from libsixel, gnuplot / ipython / matplotlib with the sixel backend, sixcat, chafa --format=sixel.

ESC P <p1>;<p2>;<p3> q  [#color-map]*  [sixel-data]*  ESC \

Output is an RGBA8 frame buffer feeding the same upload path Kitty graphics and OSC 1337 use. Decoded images get an auto-assigned id range distinct from Kitty’s, so the program’s chosen ids don’t collide.

iTerm2 inline images (OSC 1337 File=)

iTerm2 imgcat protocol · source: src/osc1337_file.rs — see OSC 1337 above for the catalog entry.

Keyboard protocols

Kitty keyboard protocol

Kitty keyboard protocol · source: src/kitty_kbd.rs

Modern programs (Neovim, Helix, modern shells, Claude Code) use the Kitty keyboard protocol to disambiguate keystrokes that collide in the legacy encoding (Ctrl+i vs Tab, Ctrl+m vs Enter, Ctrl+[ vs Esc) and to surface modifier state on every key.

ESC [ > <flags> m              push <flags> onto the stack
ESC [ = <flags> ; <mode> u     set <flags> with mode 1=set, 2=add, 3=clear
ESC [ < <n> m                  pop the top <n> stack entries (default 1)
ESC [ ? u                      query — terminal replies with current flags

Flag bits:

| Bit | Meaning | | --- | --- | | 0x1 | disambiguate escape codes (most-asked-for) | | 0x2 | report event types (press / repeat / release) | | 0x4 | report alternate keys | | 0x8 | report all keys as escape codes | | 0x10 | report associated text |

tmnl v1 tracks the flag stack and the encoder honors the disambiguate bit (0x1). The other bits are parsed for completeness so adding them is a one-spot change in encode_key_kitty. Mode-set form (CSI = flags ; mode u) parses and translates into a stack-replace event so consumers don’t have to thread the difference through.

Input modes

Focus event reporting — DECSET ?1004

xterm focus event mode · source: src/csi_modes.rs + src/shell/reader.rs (DECSET callback) + src/shell/accessors.rs (focus_reporting_enabled + write_focus_event)

When the program enables ?1004, tmnl sends ESC [ I on focus-in and ESC [ O on focus-out. Used by vim to refresh after switching away, by Claude Code / Codex to re-sync, by long-running watchers to know when to spit cached output.

The ?1004 flag is per-shell-session (focus_reporting: Arc<AtomicBool>) so two panes in the same window track their own state independently.

Mouse modes — ?1000 / ?1002 / ?1003 / ?1006

xterm mouse tracking · source: src/shell_mouse.rs

xterm mouse tracking, parameterized by which events the program wants:

| Mode | Events | | --- | --- | | ?1000 | press and release only | | ?1002 | press, release, drag (motion while a button is held) | | ?1003 | press, release, drag, and hover (any motion) | | ?1006 | SGR encoding (extended coordinates; modern canonical) |

?1006 is an encoding flag rather than a tracking mode — it can be combined with any of the above. encode_mouse honors the parser’s active encoding (SGR 1006 when set, X10 / default otherwise). Releases are encoded as button-3 in X10 (the protocol doesn’t carry the released button) and as a lowercase m terminator in SGR.

tmnl-protocol button order (LEFT=0, RIGHT=1, MIDDLE=2) gets remapped to xterm button order (LEFT=0, MIDDLE=1, RIGHT=2) at encode time; wheels (BUTTON_WHEEL_UP=4, BUTTON_WHEEL_DOWN=5) stay distinct. Modifier bits remap too: tmnl’s shift/ctrl/alt (bits 0/1/2) become xterm’s button- byte bits (2/4/3). The super modifier has no slot in xterm encoding and is dropped.

Bracketed paste — DECSET ?2004

xterm bracketed paste · source: src/csi_modes.rs + src/shell/reader.rs (DECSET callback) + src/shell/accessors.rs (bracketed_paste_enabled)

When the program enables ?2004, tmnl wraps cmd+v payloads in ESC [ 200~ … ESC [ 201~ so the shell can distinguish typed input from a paste. Modern interactive shells (zsh, bash 5.1+, fish) set the flag on init.

Tracked per-session as bracketed_paste: Arc<AtomicBool>. The OSC 52 clipboard path runs through the same paste-wrap logic. When the program hasn’t enabled ?2004, tmnl sends raw bytes — so cat > file.txt pasted into a no-bracketing context still works.

IME composition — preedit / commit / cancel

source: src/app_event_routes.rs (handler) · tmnl_protocol::ImeEvent (wire types)

IME (“Input Method Editor”) composition — typing Chinese, Japanese, or Korean text via a composition buffer. The winit-level Ime::Enabled / Disabled / Preedit(text, cursor) / Commit(text) events arrive on the window, and tmnl routes them differently per pane:

• Shell mode panes receive the committed text as raw bytes via write_bytes once composition finishes. Preedit text shows in the overlay while composing (the ime_preedit field) but doesn’t reach the shell — matching every other terminal’s behavior.
• Native-mode panes whose client advertised Caps::IME_EVENTS get the full composition state via InputEvent::Ime(Preedit | Commit | Cancel). Backing apps can render their own preedit highlight, support in-line IME composition in mnml’s editor, etc.
• Native-mode panes without the cap fall back to per-character Key(Char) events on commit, so legacy clients still receive text (just not the preedit state).

The IME pipeline is always enabled on the window via set_ime_allowed(true) at resume time; per-pane opt-in is via the protocol cap.

Native mode — tmnl-protocol

Distinct from every spec above: when tmnl runs as a “native mode” host, the pane’s backing app speaks binary tmnl-protocol over a Unix socket instead of ANSI escape codes. mnml as a tab, mixr as a tab, examples/hello_client.rs — all of these are tmnl-protocol clients.

The protocol is documented in detail at:

• SDK — building a backing app — the Client helper, the Event enum, capability negotiation, end-to-end examples.
• Native tabs — wire-level walkthrough.

Capability bitmask (Caps) flags currently defined on the Hello handshake:

| Flag | Meaning | | --- | --- | | CLIENT_COMMANDS | client exposes a ListClientCommands query the host can call to populate the palette | | FOCUS_EVENTS | client receives InputEvent::Focus(Entered | Left) | | HOVER_EVENTS | client receives InputEvent::Hover(Entered | Moved | Left) | | IME_EVENTS | client receives InputEvent::Ime(Preedit | Commit | Cancel) (see IME above) | | INLINE_IMAGES | client may send Message::InlineImageCreate / Update / Destroy (protocol v7, see Inline images below) |

Wire-level back-compat: pre-v6 peers decode to Caps::empty(), so adding a new bit doesn’t break old clients.

Pty-fd handoff (receiver) — SCM_RIGHTS

source: src/transfer.rs

A separate single-message listener at <TMPDIR>/tmnl-<pid>-transfer.sock (exported via TMNL_TRANSFER_SOCKET) accepts Message::OpenPaneTransfer with an attached pty master fd via tmnl_protocol::read_message_with_fd. The fd becomes a new adopted-shell tab on the next tick.

This can’t ride the streaming tmnl-protocol connection — SCM_RIGHTS ancillary data can’t be read through a BufReader — hence the separate socket. The sender side lives in mnml as :tmnl.pop-pty.

Inline images (protocol v7)

source: tmnl-protocol/src/lib.rs (wire types) · src/image_pipeline.rs (decoder + GPU upload)

Backing apps overlay PNG images at cell coordinates inside the pane:

Message::InlineImageCreate {
    id: u32,
    cell_row: u16, cell_col: u16,
    cell_rows: u16, cell_cols: u16,
    image_bytes: Vec<u8>,   // PNG
}
Message::InlineImageUpdate { id, ... }
Message::InlineImageDestroy { id }

tmnl decodes via the image crate, uploads to a wgpu texture, and renders through the textured-quad pipeline. The image scrolls with the underlying cells — cell-anchored, not pixel-anchored. SDK wrappers: Client::send_inline_image_create / _update / _destroy. Gated by Caps::INLINE_IMAGES. Demo: examples/inline_image_client.rs.

Three image paths, one renderer

Kitty graphics, Sixel, OSC 1337 File=, and native-mode v7 inline images all funnel into the same wgpu texture cache + textured-quad pipeline. From the renderer’s point of view, an image is an image — the protocol it arrived through is metadata.

What tmnl does not implement (yet)

In the interest of full disclosure — these are recognized specs that tmnl intentionally does not ship today, with the reasoning:

• Multi-chunk Kitty graphics (m=1) — covered by single-chunk + Sixel + OSC 1337 in practice; deferred until a real use case arrives.
• Kitty graphics animation frames — same reasoning.
• GIF in OSC 1337 File= — rare via this protocol; the Kitty graphics path is the canonical animated-image route.
• Title manipulation beyond push/pop (CSI 8 t resize, CSI 11 t iconify-state query, etc.) — the window-manipulation family is large and most slots are no-ops on macOS anyway.
• OSC 99 action buttons / sound / multi-chunk encoding — the common path (n= + body) covers gh notify, cargo build done, etc.

Next

• OSC 133 shell integration — the four marks in depth
• Attention & notifications — what surfaces from unfocused tabs
• Native tabs — the tmnl-protocol wire format
• SDK — building a backing app — Client, capability negotiation, examples
• AI completion (offline) — what rides on top of the OSC 133 anchor
